Control Your Listening Experience
Because of the way the dip switches are built, you have full adjustability for loading and wide compatibility with low output MC cartridges
Easy to use and set up
No need to stress over assembly and connection. The Fono MC is easy to assemble and set up so you can enjoy your records in no time
Valuable Investment
With everything that the Fono MC has to offer, you will definitely get your money’s worth when investing in this turntable and then some. It delivers quality of products in higher ranges.
Quality and Ease
With its high-quality polypropylene capacitors, the Fono MC brings out the full potential of every MC cartridge. While its low-noise, high-impedance Field Effect Transistor (FET) minimizes negative interactions from cartridges, playing it with ease. Adding to the arsenal are the dip switches at the back allow for acute adjustment so you can get the right sound out of your records.
Not to forget that its user-friendly design allows even the least technical music lover to enjoy the robust music experience this phono stage has to offer.
Recommended Minimum Output Load Resistance | 5k |
| Output Impedance | 200 Ω |
| Frequency Response(50 kΩ Output Load) | 13 Hz (-3 dB) to 100 kHz (-0.3 dB) |
| RIAA Accuracy (50 kΩ Output Load) | Better than ±0.2 dB 100 Hz to 100 kHz |
| Power Requirements | 24 V AC at 150 mA maximum |
| Dimensions | 398.8 x 188 x 76 mm |
| Weight | 1.2 kg |
Load settings for adjustable MC stages
| Input Loading Resistance | 1 and 2 off = 400 Ω / 1 on = 100 Ω / 2 on = 150 Ω / 1 and 2 on = 70 Ω |
| Input Loading Capacitance | Input Loading Capacitance: 3 off = 1000 pF / 3 on = 4300 pF / Gain (at 1kHz) / 4 off = 63.5 dB / 4 on = 69.5 dB |
| Maximum Input Level | (at 1 kHz): 4 off = 6.7 mV / 4 on = 3.4 mV |
| Factory Settings for all Rega MC Cartridges | Impedance 100 Ω / Capacitance 1000 pF / Gain setting high |
| Manual | Download |
